Tyre Killers Or Spike Barriers

Engineered Safety. Certified Performance.

Home|Tyre Killers And Spike Barriers

About the Product

Tyre killers, also known as spike barriers, are crucial for enhancing security at entry/exit points by deterring unauthorized vehicle access and preventing forced entry. Their primary function is to puncture the tires of vehicles attempting to enter restricted areas, thus immobilizing them and preventing further intrusion. They are particularly useful in high-risk locations like military bases, airports, and government facilities, where maintaining security is paramount.

Why do we need tyre killers Or Spike barriers

Deterring Unauthorized Access

Tyre killers act as a strong visual and physical deterrent, discouraging potential intruders from attempting to breach security perimeters.

Immobilizing Vehicles

By puncturing tires, they immediately stop vehicles, preventing them from advancing into restricted areas.

High Security Applications

They are commonly used in high-security facilities like military bases, airports, and government buildings, where unauthorized access can have serious consequences.

Versatility

Tyre killers can be deployed in various settings, including public and private spaces, to control vehicle access.

Emergency Response

They can be deployed rapidly in emergency situations, providing a quick and effective means of stopping unauthorized vehicles.

Complementing Other Security Measures

Tyre killers can be integrated with other security systems, such as boom barriers or gates, to create a multi-layered security approach.

Controlling Traffic Flow

In some applications, they can be used to manage traffic flow, preventing vehicles from entering restricted areas or driving on the wrong side of the road

Operating Options

  • Installation Depth: 355 mm / 250 mm
  • Height of spikes above the ground: 100 - 160 mm
  • Spike Type: Round Spike
  • Width: From 1 to 6 meter
  • Opening/Closing Time: 1- 2 Sec

Technical  SpacificationPECIFI

  • Mechanism : Spring loaded Mechanism (Gravitational)
  • Installation Type : Surface Mounted
  • Height of spikes above the ground: 50 mm
  • Length : 900 mm
  • Width : 400 mm

Heavy One Way Spike Or Tyre Killer

MODEL NUMBER : STK800M

Secure Gravitational tyre killer’s works in one way to stop the unauthorized intrusion. It can be installed in every place, it is design especially for defence, Critical Infrastructures & Parking lots. This tyre killer is surface mounted. All constructions are made of steel and protected by hot dip galvanization or paint in any RAL colour.

Axel Load : 25 Tons

Road Blockers

Road blockers are crucial for security and access control in various settings. They act as a physical barrier to prevent unauthorized vehicles from entering restricted areas, enhancing safety and deterring potential threats. They are commonly used in high-security locations like government buildings, military bases, and event venues, but can also be found at critical infrastructure sites like oil & gas installations and data centers.

Specific Applications

  • High-Security Areas

Road blockers are commonly used in government buildings, military bases, airports, and other sensitive locations that require a high level of security.

  • Critical Infrastructure

They are also crucial for protecting critical infrastructure like oil and gas installations and data centers.

  • Public Events

Road blockers are essential for crowd control and access management at concerts, festivals, and sporting events.

  • Construction Sites

They can be used to prevent accidents and manage traffic flow around construction zones.

Specific Applications

  • High-Security Areas

Road blockers are commonly used in government buildings, military bases, airports, and other sensitive locations that require a high level of security.

  • Critical Infrastructure

They are also crucial for protecting critical infrastructure like oil and gas installations and data centers.

  • Public Events

Road blockers are essential for crowd control and access management at concerts, festivals, and sporting events.

  • Construction Sites

They can be used to prevent accidents and manage traffic flow around construction zones.

K4 CRASH RATED ROAD BLOCKERS (M30)

Secure high security Road Blocker with level of protection K4. That Road Blocker resist 7.5 tonne vehicle at speed 48 km/hr. Heavy duty steel structure determined to destroy tthe suspension, axles & engine of a vehicle in case of unauthorized intrusion. When this Road Blocker is equipped in EFO it opens in 1 second.

Technical Specification K4 Rated

  • Rating: K4
  • Blocking Height: 550 mm
  • Blocking Width: From 1000 mm to 4000 mm
  • Installation depth: Approx. 250 mm
  • Drive: Hydraulic with power unit
  • Optional equipment: Control console, PLC, Hydraulic Power Unit and others
  • Opening/Closing Time: 3-5 Sec
  • Opening/Closing Time: 3-5 Sec
  • Safety: Line of Photocells, Loop Detectors,
  • Electrical cabinet unit: In separate cabinet
  • Works in temperature: -20°C to +60°C (optional +70°C)

Based on the traffic movement and the frequency the models are being chosen.

K8 CRASH RATED ROAD BLOCKER (M40)

Secure high security Road Blocker with level of protection K8. That Road Blocker resist 7.5 tonne vehicle at speed 64km/hr. heavy duty steel structure determined to destroy the suspension, axles & engine of a vehicle in case of unauthorized intrusion. When this Road Blocker is equipped in EFO it opens in 1.5 second.

Technical Specification

  • Rating: K8
  • Blocking Height: From 650 mm to 1200 mm (standard is 650)
  • Blocking Width: From 1000 mm to 6000 mm
  • Installation depth: Approx. 350 mm
  • Drive: Hydraulic with power unit
  • Power: 3-phase 400VAC 50Hz
  • Opening/Closing Time: 3-5 Sec
  • Safety: Line of Photocells, Loop Detectors, Microwave Radars (SMR 40)
  • Electrical cabinet unit: In separate cabinet
  • Works in temperature: -30°C to +60°C (optional +70°C)
  • Optional equipment: Control console, PLC, Hydraulic Power Unit and

K12 Crash Rated Road Blocker (M50)

Secure high security Road Blocker with level of protection K12. That Road Blocker resist 7.5 tonne vehicle at speed 80km/hr. heavy duty steel structure determined to destroy the suspension, axles, Chassis & engine of a vehicle in case of unauthorized intrusion. When this Road Blocker is equipped in EFO it opens in 1.5 second

Technical Specification : K12 rated

  • Rating: K12
  • Blocking Height: From 650 mm to 1200 mm (standard is 665)
  • Blocking Width: From 1000 mm to 6000 mm
  • Installation depth:Approx. 1500 mm
  • Drive: Hydraulic with power unit
  • Power: 3-phase 400VAC 50Hz
  • Opening/Closing Time: 3-5 Sec
  • Safety: Line of Photocells, Loop Detectors, Microwave Radars (SMR 40)
  • Electrical cabinet unit: In separate cabinet
  • Works in temperature: -30°C to +60°C (optional +70°C)
  • Optional equipment: Control console, PLC, Hydraulic Power Unit
